| SPECIFICATION OF MANUFACTURE |
|
PPC SA ÅÊ. 03.20/17.01.95 (GR-261A). |
|
|
|
|
| DRAWING OF MANUFACTURE |
|
E. & K. TASSIS CO. |
|
|
|
|
| MATERIAL OF MANUFACTURE |
|
Steel clamp is made of steel St-37. The tube body and the terminal are made of aluminium A5 99,50 % clear. The M12 Bolts, the nuts, the washers and the spring washers are made of steel. |
|
|
|
|
| SURFARCE TREATMENT |
|
The steel clamp and the bolts are hot dip galvanised according to PPC SA technical specification ×Ê 11.02 / 10.3.88 (GR-181). |
|
|
|
|
| BREAKING LOAD |
|
Q= 57000 N. |
|
|
|
|
| PPC SA CODE NUMBER |
|
 TERMINAL: 430016283
TUBE BODY: 430016295
STEEL CLAMP: 430016301 |
|
|
|
