| SPECIFICATION OF MANUFACTURE |
|
PPC SA DNEM TR-4 Revision March 2008
Dimensions according to standard IEC 60120/84 size 16Á. |
|
|
|
|
| DRAWING OF MANUFACTURE |
|
E. & K. TASSIS CO. |
|
|
|
|
| PRODUCT INDENTIFICATION NUMBER |
|
TR-4/12 |
|
|
|
|
| MATERIAL OF MANUFACTURE |
|
The body is made of forged steel St-37-2. The bolt, the nut and the washer are made of steel. The cotter pin is made by stainless steel. |
|
|
|
|
| SURFARCE TREATMENT |
|
All steel parts are hot dip galvanised according to standards EN ISO 1461/99 and ASTM A143-74 (1999). |
|
|
|
|
| MINIMUM BREAKING LOAD |
|
Q=100 kN. |
|
|
|
