Clamp use		Fast and permanent repair of damaged pipes above ground in case of longitudal cracks and local small damages.



Damage types		Pin holes, frost damage, local small damages, longitudal cracks.



Pipe types		Ductile Iron, Copper, Cast Iron, Steel.



Working pressure		16 bar.




Material Specification **



Band		One stainless steel band according to AISI 304.



Lugs		Stainless steel according to AISI 304.



Bolts		Stainless steel AISI 304 M10 Mushroom head square neck bolt.



Nuts		Stainless steel AISI 304 M10 Hexagon Nut DIN 934.



Washers		Stainless steel AISI 304 M10 Washer DIN 125 A.



Rubber Gasket		EPDM suitable for use in potable water.



Tightening torque		5 Kg / m



Bolts have a coating wth special material so as galling is prevented during nuts clamping. All metal parts after welding have been subjected to pickling and passivation process for restoring corrossion resistance. Easy installation and use. No loose parts



AVAILABLE SIZES
For pipe OD 19 mm up to pipe OD 37 mm.

WORKING RANGE*
2-5 mm.

CLAMP LENGTH *
76 mm.

* OTHER CLAMP WORKING RANGES AND CLAMP LENGTHS ARE MANUFACTURED ON SPECIAL DEMAND. ** MATERIAL AISI 316 ON REQUEST.
