| Clamp use |
|
Fast and permanent repair of damaged pipes above ground in case of full circumferental damage. |
|
|
|
|
| Damage types |
|
Full circumferental damage, Pin holes, frost damage, local small damages, longitudal cracks. |
|
|
|
|
| Pipe types |
|
Ductile Iron, Cast Iron, Steel, Asbestos Cement (AC), PE coated steel, PVC, PE.
|
|
|
|
|
| Working pressure |
|
16 bar. |
|
|
|
| Key benefits of using our repair clamps |
|
 |
Top leakage sealing performance under pipe working pressure with the use of high performance closing mechanism. |
|
High quality guarantee. |
|
Top manufacturing quality. |
|
Fast, easy installation and use with the help of a simple wrench. |
|
No loose parts. |
|
Small weight. |
|
No pressure loss during installation. |
|
|
|
|
|
| |
| Material Specification * |
|
|
|
| Band |
|
One stainless steel band according to AISI 304. |
|
|
|
|
| Lug |
|
Stainless steel according to AISI 304. |
|
|
|
| U-shaped lifter bar |
|
Stainless steel according to AISI 304. |
|
|
|
| Sidebars |
|
Stainless steel according to AISI 304. |
|
|
|
| Armor |
|
Stainless steel according to AISI 304. |
|
|
|
|
| Bolts |
|
One stainless steel AISI 304 M10 stud. |
|
|
|
| Nuts |
|
One stainless steel AISI 304 M10 Hexagon Nut DIN 934. |
|
|
|
|
| Washers |
|
One stainless steel AISI 304 M10 Washer DIN 125 A. |
|
|
|
|
| Rubber Gasket |
|
Waffle pattern EPDM suitable for use in potable water. |
|
|
|
|
| Tightening torque |
|
5 Kg / m |
|
|
|
|
Studs have a coating with special material or PTFE TEFLON so as galling is prevented during nuts clamping.
All metal parts after welding are subjected to pickling and passivation process for restoring corrosion resistance.
|
|
|
|
| AVAILABLE SIZES |
| For pipe OD 26 mm up to pipe OD 30 mm. |
|
| WORKING RANGE* * |
| 4 mm. |
|
| CLAMP LENGTH * * |
| 76 mm. |
|
* MATERIAL AISI 316 ON REQUEST.
** OTHER CLAMP WORKING RANGES AND CLAMP LENGTHS ARE MANUFACTURED ON SPECIAL DEMAND. |
|
|
